• Wifi Smart control Capability*
• Cooling 2.5kw Heating 3.2kw
• Corrosion Resistance Black Fin Coated
• Built In drain pump
• Two Thermistor Control
• Flexible Installation and Maintenance

Twin Rotary Inverter Compressor

Twin Rotary Inverter Compressor consists of stable and optimised structures with low vibration and low noise characteristic

Quiet Operation (Low Static Pressure Model)

The noise level of low static ducts have been reduced, even though ESP has been increased

Wi-Fi Smart Control Compatible

Come Home to Comfort

The LG ThinQ® App* lets you access and control your air conditioner with your smartphone* even when you're not at home, so you can come home to comfort. (Optional Wi-Fi dongle module sold separately).

*LG ThinQ® app available on compatible Android or iOS smartphones. Phone and Home Wi-Fi Data connection and product registration with LG ThinQ® required. Visit lg.com/au/lg-thinq for features, system compatibility and service availability which may vary by country and model.

Corrosion Resistance Black Fin

The black coating with enhanced epoxy resin is applied for strong protection from various corrosive external conditions such as salt contamination and air pollution including fumes from factories.

Flexible Installation (Low Static Pressure Model)

Standard Inverter low static duct allows the air intake at the rear or bottom under installation condition.

Easy Service & Maintenance (Low to Mid Static Pressure model)

Users are not required to disassemble the whole panel for maintenance; since panel is divided into 2 components; one for heat exchanger and the other for fan / motor. The user can easily detach and re-attach the filter in the available limited space

E.S.P. (External Static Pressure) Control

This function easily controls the volume of air with a remote controller. The Brushless DC (BLDC) motor can control fan speed and air volume regardless of the external static pressure. Additional accessories are not required to control air flow.

High Head Drain Pump

The high head drain pump automatically drains water up to a height of 700mm of drain-head height. It provides the perfect solution for the draining of water.

Two Thermistors Control

The indoor temperature can be checked using the thermistors in the remote controller as well as from the indoor unit. There may be a significant difference between ceiling and floor air temperature. Two thermistors can optimised indoor air temperature for a more comfortable environment.

COMBINATIONAL SPECIFICATION

• Cooling Capacity-Rated ²⁾(kW)

  2.50

  Cooling Capacity-Min ~ Max(kW)

  1.50~3.20

• Heating Capacity-Rated ²⁾(kW)

  3.20

  Heating Capacity-Min ~ Max(KW)

  1.80~4.00

• AEER

  3.640

  ACOP

  4.173

• Rated Current-Cooling(A)

  3.00

  Rated Current-Heating(A)

  3.30

• Full Load Amps(A)

  10.0

  Air Flow Rate-Rated(L/s)

  192

• Air Flow Rate-Min ~ Max(L/s)

  107~248

  External Static Pressure-Min ~ Max(Pa)

  0~49

• Indoor-Net(W x H x D)(mm)

  900 x 190 x 460

  Indoor-Net Weight(kg)

  18

• Indoor-Cooling ((SH)/H/M/L)(dB(A))

  - / 35.0 / 30.0 / 27.0

  Outdoor-Cooling / Heating (@ 1.5m height)(dB(A))

  49.0 / 52.0

• Power Supply(Ø , Hz , V)

  1 , 50 Hz, 220-240 V

  Compressor-Type

  Twin Rotary

• Compressor-Motor Type

  BLDC

  Heat Exchanger-Fin Type

  Wide Louver Plus

• Heat Exchanger-Corrosion Protection (Coating)

  Black 2

  Refrigerant-Type

  R32

• Refrigerant-Pre-charge Length(m)

  7.5

  Pipe size-Liquid(mm(inch))

  Φ6.35 (1/4)

• Pipe size-Gas(mm(inch))

  Φ9.52 (3/8)

  Pipe size-Drain Pipe (Drain Pump) OD/ID-(mm(inch))

  Ø 32(1-1/4) / 26(1-1/32)

• Piping Length-IDU - ODU (Rated / Max / Min)(m)

  7.5 / 30 / 5.0

  Maximum Height Difference -IDU - ODU (Max)(m)

  30

• Supply Air Opening-H x W, Flange (Discharge) (mm)

  148 x 860

  Return Air Opening-H x W, Flangeless(mm)

  190 x 807

• Continuous Operation-Cooling(°C (DB))

  -15 ~ 48

  Continuous Operation-Heating(°C (WB))

  -18 ~ 18

• Wi-Fi Compatible⁴⁾

  Optional

DISCLAIMER

• Disclaimer

  1 Capacities are based on following conditions.
  • Cooling: Indoor Temp 29°C DB / 19°C WB, Outdoor Temp 35°C DB / 24°C WB
  • Heating: Indoor Temp 20°C DB, Outdoor Temp 7°C DB / 6°C WB
  3. This product contains fluorinated greenhouse gases. (R32)
  4. (Sold separately) Dongle required for Wi-Fi Connectivity. Internet connection required.
