Auto E.S.P. (External Static Pressure) Setting

E.S.P. control function enables control of air volume easily with a remote controller. The Brushless DC (BLDC) motor can control fan speed and air volume regardless of the external static pressure.Set RPM by simple touch on remote control to change airflow.

AUTO External Static Pressure + Zone Control (On/Off)

LG’s high static ducted unit does step control (High-Mid-Low Speed) to supply airflow rate to each zone depending on the number of open dampers.

Twin Rotary Inverter Compressor

Twin Rotary Inverter Compressor consists of stable and optimised structures with low vibration and low noise characteristic

Night Operation

Night Operation can reduce noise levels at night time by simply setting the dip switch on the PCB of the outdoor unit.

Minimised Height

Slim ducts provide an ideal solution for installation in limited space.

Corrosion Resistance Black Fin

The black coating with enhanced epoxy resin is applied for strong protection from various corrosive external conditions such as salt contamination and air pollution including fumes from factories.

High Head Drain Pump

The high head drain pump automatically drains water up to a height of 700mm of drain-head height. It provides the perfect solution for the draining of water.

Two Thermistors Control

The indoor temperature can be checked using the thermistors in the remote controller as well as from the indoor unit. There may be a significant difference between ceiling and floor air temperature. Two thermistors can optimised indoor air temperature for a more comfortable environment.

E.S.P. (External Static Pressure) Control

This function easily controls the volume of air with a remote controller. The Brushless DC (BLDC) motor can control fan speed and air volume regardless of the external static pressure. Additional accessories are not required to control air flow.

Wi-Fi Smart Control Compatible

Come Home to Comfort

The LG ThinQ® App* lets you access and control your air conditioner with your compatible smartphone even when you're not at home, so you can come home to comfort. (Optional Wi-Fi dongle module sold separately).

*LG ThinQ® app available on compatible Android or iOS smartphones. Phone and Home Wi-Fi Data connection and product registration with LG ThinQ® required. Visit lg.com/au/lg-thinq for features, system compatibility and service availability which may vary by country and model.
Image used for illustrative purposes only. Actual user interface may differ with updates to ThinQ app from time to time

UVnano^TM Filter Box (Optional Accessory*)

LG UVnano Filter Box can effectively create a safe indoor environment by trapping and removing various harmful substances such as Ultrafine dust, bacteria and viruses in the form of droplets.

Download Ducted Brochure

Download a copy of the Ducted brochure for more information.

DOWNLOAD

•  PDF SPEC SHEET

CLOSE

COMBINATIONAL SPECIFICATION

• Cooling Capacity-Rated ²⁾(kW)

  8.00

  Cooling Capacity-Min ~ Max(kW)

  3.10~9.00

• Heating Capacity-Rated ²⁾(kW)

  9.00

  Heating Capacity-Min ~ Max(kW)

  3.60~10.10

• AEER

  3.448

  ACOP

  3.383

• Rated Current-Cooling(A)

  9.90

  Rated Current-Heating(A)

  11.70

• Full Load Amps(A)

  17.0

  Air Flow Rate-Rated(L/s)

  367

• Air Flow Rate-Min ~ Max(L/s)

  240 ~ 477

  External Static Pressure-Min ~ Max(Pa)

  25 ~ 147

• Indoor-Net(W x H x D)(mm)

  900 x 270 x 700

  Indoor-Net Weight(kg)

  25.0

• Indoor-Cooling ((SH)/H/M/L)(dB(A))

  - / 37.0 / 35.0 / 34.0

  Outdoor-Net(W x H x D)(mm)

  950 x 834 x 330

• Outdoor-Net Weight(kg)

  59.0

  Outdoor-Cooling / Heating (@ 1.5m height)(dB(A))

  50.0 / 52.0

• Power Supply(Ø , Hz , V)

  1 , 50 Hz, 220-240 V

  Compressor-Type

  Twin Rotary

• Compressor-Motor Type

  BLDC

  Heat Exchanger-Fin Type

  Wide Louver Plus

• Heat Exchanger-Corrosion Protection (Coating)

  Black 2

  Refrigerant-Type

  R32

• Refrigerant-Pre-charge Length(m)

  10

  Pipe size-Liquid(mm(inch))

  Φ9.52 (3/8)

• Pipe size-Gas(mm(inch))

  Φ15.88 (5/8)

  Pipe size-Drain Pipe (Drain Pump) OD/ID-(mm(inch))

  Ø 32(1-1/4) / 26(1-1/32)

• Piping Length-IDU - ODU (Rated / Max / Min)(m)

  7.5 / 50 / 5.0

  Maximum Height Difference -IDU - ODU (Max)(m)

  30

• Supply Air Opening-H x W, Flange (Discharge) (mm)

  200 x 857

  Return Air Opening-H x W, Flangeless(mm)

  231 x 849

• Continuous Operation-Cooling(°C (DB))

  -15 ~ 48

  Continuous Operation-Heating(°C (WB))

  -18 ~ 18

• Wi-Fi Compatible⁴⁾

  Optional

CONVENIENCE

• ThinQ(Wi-Fi)

  Optional

DISCLAIMER

• Disclaimer

  1. Capacities are based on following conditions. • Cooling: Indoor Temp 29°C DB / 19°C WB, Outdoor Temp 35°C DB / 24°C WB • Heating: Indoor Temp 20°C DB, Outdoor Temp 7°C DB / 6°C WB 2. (Sold separately) Dongle required for Wi-Fi Connectivity. Internet connection required.
